Excella
Check Reading and Imaging Device built for Efficiency
Countertop Check Reader Focused on Efficiency
With a small footprint and striking modern design, Excella is an auto-feed check reader
Check Reader with 70 Document Capacity
Captures both the front and back image of checks in a single pass at 45+ DPM. The automatic feeder has a capacity of up to 70 documents to support BOC, Check 21, and remote deposit capture.
Dual-Sided Scanner, Back Franking
Excella reads both E13B and CMC7 MICR fonts and features a programmable endorsement message.
Scans at a Resolution that Works
Captures check images at a 200 dpi. Offers CCITT G4 or JPEG image compression to optimize your applications’ storage use.
| Imaging | |
|---|---|
| MICR Encryption | NO |
| Magstripe Reader | SCRA 3TK |
| Printer | BACK Printing on all models, FRONT franking on most models |
| Scanner | Dual Sided |
| Image Rendition | TIFF 6.0 JFIF with EXIF tags BMP |
| Image Compression | CCITT G4 or JPEG |
| Image Resolution | 200 dpi; black/white and grayscale images; color optional |
| Check Capacity | Single Feed |
| Specifications | |
| MTBF | Electronics: 125,000 hrs |
| Check Read Head | 1 MILLION PASSES |
| MSR Read Head | 1 MILLION PASSES |
| Document Size | 4" x 8.5" Maximum |
| MICR Fonts | E13-B and CMC-7 |
| Interface | USB 2.0; Ethernet 100 Base-T |
| Current | 300 mA; 1.5 A Max |
| Voltage | 24 VDC, 2.5 Amps |
| Mechanical | |
| Dimensions |
Height: 6.3 in Width: 6.3 in Length: 9.4 in |
| Weight | 4.3 lbs |
| Environmental | |
| Temperature |
Operating: 0°C to 50°C (32°F to 122°F) Storage: -30°C to 60°C (-22°F to 140°F) |
| Humidity |
Operating: 10% to 90% noncondensing Storage: Up to 95% noncondensing |
| Altitude |
Operating: 0 - 10,000 ft (0 - 3,048m) Storage: 0 - 50,000 ft (0 - 15,240m) |
